What documentation is available for composite panels?

Supply includes the reaction-to-fire classification pending documentation classification for the felt material, NRC data measured to ASTM C423 for the proposed build-up, and dimensional and weight data. Additional documentation can be requested during quotation.

Can performance be specified to a target NRC?

Yes. Because the build-up controls the result, the panel thickness, cavity and any additional insulation are selected together to reach the target for the room. Provide the room, the frequency problem and the target and the build-up is proposed for approval.

Illustrative render

High-performance architectural panels

Composite Panels

CYC Acoustic Composite Panels are built-up acoustic panels for specification-driven projects. They combine recycled PET felt with additional layers so performance can be tuned to the room, and are supplied with the technical documentation required for commercial specifications, including reaction-to-fire classification pending documentation classification.

reaction-to-fire classification pending documentation · NRC to ASTM C423

Priced per project

Tell us the space and we will quote it — usually within one working day. Small orders are quoted per order and paid through a secure link.

Request a quote Order a sample box

Questions? Ask JARVIS, our assistant, any time.

Specification

Core material	Needle-punched post-consumer recycled PET felt (panel core)
Sheet size	2440 × 1220 mm (96" × 48")
Thickness	Built up to specification
Weight	1.0–2.5 kg/m², thickness dependent
Sound absorption (NRC)	Tuned to the project — request the NRC table for the proposed build-up (ASTM C423)
Fire classification	Fire classification pending documentation
Installation	Project specific — fixing method reviewed with the design team
Colours	16 stock colours (CYC Colour Collection) plus custom colour and size
Pricing	Quoted per project — request a quote

NRC values are measured to ASTM C423 and depend on panel thickness and mounting method (direct fix, 25 mm cavity, or insulated build-up). Reaction-to-fire classification pending documentation is a reaction-to-fire classification, not a fire-resistance rating. We do not currently hold an ASTM E84 classification. Recycled-content and recyclability claims apply to the panel core.

Why this system

Performance tuned to the room, not just the panel
Technical documentation pack for specifications
Project-specific build-ups and fixing methods
Factory-direct supply for larger project quantities

Typical applications

Commercial fit-out
Specification-driven interiors
Education and healthcare
Hospitality projects
Performance and media spaces

Colours

16 stock colours in the CYC Colour Collection, plus custom colour and size. Order a sample box to match colour and texture in your own lighting.

Dark Vanilla

Milk

Flint

Sage Leaf

Stone Grey

Eminence

Auburn Red

Garnet

Klein Blue

Hickory

Nadeshiko Pink

Space Cadet

Dark Purple

Hibiscus

Black Rock

Dark Turquoise

Colour swatches are approximate screen representations only — felt reads differently under warm and cool light. Order a sample box to confirm colour and texture before specifying.
